Main feature
●Control system: Delta PLC, production order can be saved and recalled to save changing time. Memorize system for easy operation and maintenance.
● Double servo feeding system, each row of feeding wheels is driven by independent servo motor, high precision and low noise, non-feeding rollers in feeder to prevent the corrugated wave from damaging.
● Printing: Adopt famous brand anilox roll and rubber roll to ensure high-quality printing.
●Slotter: computerized control the box length, width and box height, fast and convenient.
●Die cutter: independent engine drive controlled by KEB servo system from Germany to ensure the die cutting accuracy.
Surface speed compensation system. Die cylinder shifts when running to prolong the life of rubber anvil.
● Gears are made of high-quality chrome steel, heat treated and grinded to ensure the high stability and precision.
● Bearings and electrical components are all famous
brand in Taiwan and in China.
Parameter
|
Model |
YKM1832 |
YKM1835 |
YKM1838 |
YKM1840 |
|
|
Speed(sheet/min.) |
140 |
140 |
140 |
140 |
|
|
Max. feeding size(mm) |
1800X3200 |
1800X3500 |
1800X3800 |
1800X4000 |
|
|
Min. feeding size(mm) |
460X700 |
460X700 |
460X700 |
460X700 |
|
|
Max. printing size(mm) |
1800X3100 |
1800X3400 |
1800X3700 |
1800X3900 |
|
|
Max. die cutting size(mm) |
1800X3150 |
1800X3450 |
1800X3750 |
1800X3950 |
|
|
Min. slotting size(mm) |
Normal |
165X165X165X165 |
165X165X165X165 |
165X165X165X165 |
165X165X165X165 |
|
Reverse |
320X60X320X60 |
320X60X320X60 |
320X60X320X60 |
320X60X320X60 |
|
|
Slotting knife width X length(mm) |
7X450 |
7X450 |
7X450 |
7X450 |
|
|
Printing plate thickness(mm) |
4-9 |
4-9 |
4-9 |
4-9 |
|
|
Corrugated board thickness(mm) |
2-12 |
2-12 |
2-12 |
2-12 |
|
