Usage
Widely used for compressing waste cardboards, cartons, paper, plastic film, straw etc. which are popular in packaging and corrugation industrial, bear breweries, recycling center as well as in printing plants etc. Conveyor is optional for conveniently feeding the waste to the chamber.
Parameter
|
Model |
JP-60T |
JP-80T |
|
Pressure |
60tons |
80tons |
|
Main Motor Power |
22kw |
37.5kw |
|
Cooling System |
air cooler / water cooler |
air cooler / water cooler |
|
Cycle Time (unload) |
24s |
16s |
|
Oil Reservoir |
1000L |
1100L |
|
Number of Belting |
4lines |
4lines |
|
Wire Size |
Ø2.7-3.0 |
Ø2.7-3.0 |
|
Feed Opening Size (L*W) |
1600*1050mm |
1600*1050mm |
|
Chamber Size (L*W*H) |
2100*1100*750mm |
2100*1100*750mm |
|
Bale Size (L*W*H, L is adjustable) |
L*1100*750mm |
L*1100*750mm |
|
Bale Density（OCC） |
400-500kgs/m3 |
420-500kgs/m3 |
|
Throughput (30-60kgs/m3) |
3-7tons/h |
4-8tons/h |
|
Machine Weight |
13tons |
14tons |
|
Machine Overall Dimension |
7950*3950*3500mm |
8100*3900*3500mm |
|
Feeding Device |
Conveyor |
Conveyor |
|
Conveyor |
||
|
Feeding Width |
1600mm |
1600mm |
|
Speed |
12m/min |
12m/min |
|
Power |
4/5.5KW |
4/5.5KW |
|
Weight |
5tons |
5tons |
|
Overall Dimension |
9000*2100*4500mm |
9000*2100*4500mm |
